A series of multi-technology, contactless access control to properly secure your properties or business.
Product Description:
Alarm.com’s Smarter Access Control is a powerful, easy-to-use solution for commercial properties that seamlessly integrates with the Alarm.com for Business platform. This platform enables intelligent automation and features, such as disarming when badging in, locking doors when arming, and tagging access events on the video timeline.
These three multi-technology contactless access control readers offer a modern aesthetic
and a state-of-the-art feature set, including Proximity (125 kHz), MIFARE DESFire (13.56
MHz), NFC, and Bluetooth®. All readers are fully OSDPTM compliant and are enabled for OSDP Secure Channel.
Product Features:
- Multiple technologies in a single reader: Proximity, MIFARE DESFire, NFC & BLE
- Mobile Credentials support enables phones to unlock doors, eliminating badges
- OSDP Auto-Detect
- OSDP Secure Channel and remote firmware upgradability
- MIFARE DESFire® EV1 & EV2 support
- LEAF credential support for secure, open, interoperability
- FSK and ASK legacy proximity credentials support for seamless transitions
- Accelerometer-based tamper detection Tri-state LED light bar (red, green, amber) and audible beeper
- Accommodates indoor, outdoor installation environments
Technical Specification:
| RF Technologies | 125 KHz, 13.56 MHz, NFC,Bluetooth Low Energy |
| Reads | MIFARE DESFire® EV1 & EV2, LEAF, FSK and ASK proximity |
| Input power | 5-16 VDC, 144 mA max (ET10),169 mA max (ET20), 193 mA max (ET25) |
| Output | OSDP, Wiegand, accelerometer-based tamper detection |
| Read ranges | EV1: 1.2”, EV2: 2.2”, 125 kHz up to 4” |
| Temperature | -31°F – 151°F (-35°C – 66°C) |
| Dimensions | 5.1 x 1.7 x 0.7” (13.0 x 4.3 x 1.8cm) (ET10), 5.1 x 3.3 x 0.7” (13.0 x 8.4 x 1.8cm) (ET20 & ET25) |
| Operating Humidity | 5 – 95% (non-condensing) RH |
| Weight | 7 oz (ET10), 10 oz (ET20), 11.3 oz (ET25) |
| Country of Origin | USA |
| Weight | Weight: 7 oz (ET10), 10 oz (ET20), 11.3 oz (ET25) |
| Certifications | FCC, IC, CE, UL 294,EN 302291, EN 301489, EN 300330,EN 50130-4, IP55, BIS IS 13252 |
