An easy-to-carry device designed to detect all cellphones and ferrous contraband, particularly in prisons.
Description:
The illegal use of cell phones is a growing and dangerous problem in correctional institutions worldwide. These devices are a significant threat to prison security and circumvent the monitoring processes in prisons, while allowing inmates to commit new crimes both inside and outside the facility. The MSD™ was specifically designed to detect all cell phones and ferrous contraband concealed on the person or in body cavities (including key fob cell phones, smart phones, radio transceivers, etc.) quickly and easily. The one-piece design allows the MSD™ to be easily transported and operational in 10 seconds.
Product Features:
- Detection of all cell phones and ferrous contraband concealed on the person or in body cavities (including keyfob cellphones, smart phones, radio transceivers, etc.)
- Constant Sensitivity across the detection area in pass-through operations
- Multi-Zone targeting indication identifies location of contraband on the body
- Covert operation through use of BT wireless headset
- Fully weather proof for outdoor use (IP65 certified)
- 26 hours continuous use on embedded battery operation
- Unmatched detection in all environments without adjustment
- Extremely durable design
- No assembly required: set-up in less than 10 seconds
Technical Specifications:
| Controls and indicators | ON/OFF push-button4-key keypad, for programming and status readoutProgramming of operational parameters and downloading of data logger by smartphone or portable PC SECURITYPassword protected programming at User and Supervisor level MULTI-COLOR STATUS AND ALARM WARNING LIGHTGREEN LIGHTNormal operation, no alarm YELLOW LIGHTDetection of ferromagnetic object below alarm threshold RED LIGHTDetection of ferromagnetic object above alarm threshold:Full height alarm indicationIndication proportional to signal intensityAlarm indication with 5 different localization zonesFull height alarm indication, followed by zonal signalingBlinking light: diagnostics alarm BLUE LIGHT- Connecting BT wireless device in progress ALARM SOUNDERAlarm indication for target over the alarm threshold:Fixed toneTone proportional to signal intensitySingle pulse for pinpointing targetAlarm tone can be selected, continuous and intermittentSelf-diagnostics signal: intermittent tome BT HEADSET (ACCESSORY)Copies all acoustic indications, with the addition of checking BT connection |
| Power supply | AC/DC external power adapter: 100 … 240 V~ , 47…63Hz, 40W Embedded rechargeable battery16h typical / 17h max. of continuous operation with 3 h battery charge24h typical / 26h max. of continuous operation with 4.5 h battery charge |
| Detector environmental conditions | Working temperature: -10°C to +65°CStorage temperature: -37°C to +70°CRelative humidity: 0 to 95%, non-condensing |
| Weight | MSD™: 9,5 kgAC/DC adapter: 0,7 KgBT wireless communication kit: 0,2 Kg (includes battery charger)Carrying case: 0,6 KgInstallation kit: 0,3 Kg |
| Dimensions | Height: 1900 mm; Width: 330 mm |
| Shipping information | Dimensions (WxDxH) 400 mm x 2000 mm x 480 mmWeight 24 Kg |
| Degree of protection | Fully weather proof for outdoor use (IP65) |
| Available accessories | EVO function activation; code 88918BT wireless audio function activation. Includes a headset with AC/DC charger; code 88919MSD™-RRU Remote Relay Unit; code MSD™-RRUApp CEIA FMD: the application allows monitoring of the device, adjustment of the settings and downloading of data logger. Available on Google Play Store. REQUIREMENTS: Android 7.0 or later, BT interface availableSolid rubber feet; code 88917MSD™ Demo Kit – Kit of demonstration objects, consisting of: BT wireless headset • Hair pins • Hospital pager • Magnet • Medical scissors • Micro cell phone • Micro smartphone • Needle • Razor blades • Transceiver • Voice recorder; code 89052MSD™ Maintenance Kit: Set of main spare parts and necessary tools; code 89051MSD™ Training Kit: Set of innocuous items tampered creating a concealed space for hiding small size threat objects; code 89054MSD EVO™ ConnectingCable Length 2.7 m; code 95376Length custom, up to 25 m code 95494Standing mat: self-adhesive mat with indication of position and rotation; code 94590 |
| Certification and compliance | Safe for use for pace-makers and other medical implantsCompliant and certified to the applicable electromagnetic Standards on Human Exposure and pacemaker safetyCompliant with and certified to the applicable International Standards for electrical safety and EMC |
